E91 is a wired smart programmable thermostat designed for electric floor heating systems,
offering precise temperature control, adjustable differential, and reliable wired connection.
Description
E91 Wired Smart Programmable Thermostat is designed for room temperature control in electric floor
heating systems. With a wired connection, it ensures stable and reliable operation and is suitable
for residential and commercial electric heating applications.
The thermostat operates on AC 230V 50–60Hz power supply with low power consumption of 2W.
It supports a wide temperature setting range from 5℃ to 90℃, which can be adjusted according
to application requirements. External temperature limitation can be set from 5℃ to 60℃,
with a factory default setting of 35℃ to protect floor heating systems.
With an adjustable switch differential from 0.5℃ to 10℃ and a factory default of ±1℃,
the E91 provides stable temperature regulation and user comfort.
Featuring IP20 protection rating and anti-flammable PC housing, the thermostat is suitable
for safe indoor installation in electric floor heating control systems.
- Wired smart programmable thermostat
- Designed for electric floor heating systems
- AC 230V power supply, 50–60Hz
- Low power consumption: 2W
- Wide temperature setting range: 5–90℃
- External temperature limitation: 5–60℃
- Adjustable switch differential: 0.5–10℃
- Factory default differential: ±1℃
- IP20 protection rating
- Anti-flammable PC housing
| Model | E91 |
| Product Type | Wired Smart Programmable Thermostat |
| Application | Electric Floor Heating |
| Power Supply | AC 230V, 50–60Hz |
| Power Consumption | 2W |
| Temperature Setting Range | 5–90℃ (adjustable) |
| External Limitation Range | 5–60℃ (default 35℃) |
| Switch Differential | 0.5–10℃ (default ±1℃) |
| Ambient Temperature | 5–50℃ |
| Protection Rating | IP20 |
| Housing Material | Anti-flammable PC |
- Electric floor heating systems
- Room temperature control
- Residential electric heating
- Commercial electric heating projects
- OEM and project-based heating solutions
